MOTU UltraLite mk4

5,776.00kn (~ 767,83 €)

MOTU UltraLite mk4

Nema na zalihi

SKU: MOTU UltraLite mk4 Kategorije: , Oznaka:

MOTU UltraLite mk4

18×22 USB audio interface with

DSP, mixing and effects

The latest in MOTU’s award-winning UltraLite series, the UltraLite-mk4 is a USB audio interface with 40 simultaneous I/O channels (18 in, 22 out). It also delivers exceptional sound quality, new ultra-low latency drivers and expanded DSP for studio-grade mobile audio recording.

Web app control

The software that you use to control the UltraLite-mk4 doesn’t reside on your hard drive. It’s a web app served from the hardware itself. This means you can control the UltraLite-mk4’s on-board DSP, mixing, and device settings from the web app software running in your favorite web browser on the computer, or even a tablet or smartphone on the same Wi-Fi network as your computer.

Superb audio quality

Analog outputs deliver 117dB dynamic range at sample rates up to 192 kHz. Renowned drivers deliver rock-solid performance and industry-leading low latency.



Ultra-low latency

New, optimized drivers for both Mac and PC deliver ultra-low latency performance. With a high-performance DAW such as Digital Performer, the UltraLite-mk4 delivers an astonishing round trip latency (RTL) of 1.83 ms (milliseconds) on OS X and 1.84 ms on Windows over USB (at 96 kHz with a 32-sample host buffer).

Built for studio and stage

Housed in a compact, aluminum-alloy
enclosure you can take anywhere, the
UltraLite-mk4 is equally well-suited
for studio and stage, with or without a
computer. As an interface or mixer, the
UltraLite-mk4 provides 18 ins and 22
outs, for a total of 40 simultaneous
I/O channels.

Solid Metal Chassis

The UltraLite-mk4 aluminum chassis is lightweight, yet incredibly sturdy and durable, and designed to withstand the rigors of the studio, stage, and tour bus. In a world awash with cheap plastic, the cool touch of the UltraLite-mk4’s metal exterior in your hands is a reassuring reminder that you are holding quality engineering and construction built to last.



Technical Specifications

Sample rates 44.1, 48, 88.2, 96, 176.4, 192 kHz
Mic/guitar inputs 2 x combo XLR/TRS mic/guitar inputs
Preamp gain: 0 to +60 dB (digitally controlled)
Instrument gain: 0 to +30 dB (digitally controlled)
Analog inputs 6 x 1/4″ TRS line inputs (balanced/unbalanced)
Max level: +24 dBu (digitally adjustable -96 to +22)
Analog outputs 10 x 1/4″ TRS line out (balanced, DC coupled)
Max level: +20 dBu (digitally adjustable -4 to +20)
1 x 1/4″ TRS stereo headphone
Digital I/O 1 bank (8 ch) of ADAT optical at 1x sample rates
1 bank (4 ch) of SMUX optical at 2x sample rates
Switchable to stereo TOSLink (optical S/PDIF)
Total I/O 18 in / 22 out (40 total) at 1x sample rates
14 in / 18 out (32 total) at 2x sample rates
8 in / 12 out (20 total) at 4x sample rates
Computer I/O 1 x USB 2.0 audio class compliant
USB 3.0 and iOS compatible
Computer I/O channels 64 in/out at 1x (44.1 to 48 kHz)
32 in/out at 2x (88.2 to 96 kHz)
24 in/out at 4x (176.4 to 192 kHz)
MIDI I/O 1 x MIDI IN
1 x MIDI OUT
16 MIDI channels to/from computer host
Headphone 1 x 1/4″ TRS stereo phone (assignable)
Phantom power 2 x individual +48V
Front panel 1 x 1/4″ TRS headphone output
2 x XLR/TRS combo inputs
1 x digital rotary encoders • main/phone vol/pwr
2 x digital rotary encoders • mic/instr input gain
4 x switches • (2) Pad and (2) 48V Phantom pwr
128 x 48 pixel LCD for level meters / menu nav
Power External 12-18V DC power supply
1.0A max • tip pos or neg

Mac System Requirements

  • 1 GHz Intel-based Mac or faster
  • 2 GB RAM; 4 GB or more recommended
  • Mac OS X version 10.8 or later
  • Available USB 2.0 or 3.0 port
  • A large hard drive (at least 500 GB for recording)

Windows System Requirements

  • 1 GHz Pentium-based PC compatible or faster
  • 2 GB RAM; 4 GB or more recommended
  • Windows 7, 8 or 10
  • Available USB 2.0 or 3.0 port
  • A large hard drive (at least 500 GB for recording)

Web App Support

  • Any web client platform: Mac, Windows, Linux, iOS, Android
  • Any web browser: Safari, Firefox, Chrome, Opera, Explorer, etc.

Included Software

  • MOTU Discovery App for Mac & Windows (finds connected MOTU interfaces)
  • MOTU Discovery App for iOS (available from Apple App Store)
  • MOTU Control web app (served from the hardware itself)
  • AudioDesk 4.0 for Mac & Windows (separate download)

Operating Systems

  • For computer audio I/O: Mac OS X 10.8 or later; Windows 7 or later
  • For web app control: Mac, Windows, Linux, iOS, Android

Brand

MOTU
