Roland SYSTEM-1m

PLUG-OUT Synthesizer

SEMI-MODULAR PLUG-OUT SYNTHESIZER WITH CV/GATE AND EURORACK COMPATIBILITY

The SYSTEM-1m is a semi-modular synthesizer with PLUG-OUT capability and a unique design that can be used as a Eurorack module, tabletop synth, or 19” rackmount unit. In addition to being a powerful standalone instrument, the SYSTEM-1m has external inputs and an array of CV/Gate connections that allow it to be re-patched and to interface with other modular synthesizer systems. The SYSTEM-1m’s CV/Gate connections combined with its ability to load classic Roland PLUG-OUT synth models like the SH-101 and PROMARS give it power and flexibility that is simply unparalleled.

SOUND GENERATOR SECTION

Maximum Polyphony4 voices (SYSTEM-1m Mode)
User Memory64 (8 memories x 8 banks)

Structure Elements (SYSTEM-1m Mode)Oscillator Section
Waveform: SAW, SQUARE, TRIANGLE, SAW 2, SQUARE 2, TRIANGLE 2
Knobs: COLOR, MODULATION Source (MANUAL, LFO, P. ENV, F. ENV, A. ENV, SUB OSC), OCTAVE, TUNE
Envelope: ATTACK Time, DECAY Time, ENVELOPE Depth
Modulation: CROSS Modulator, RING Modulator, Oscillator SYNC
Sub Oscillator: -1 oct/-2 oct
Noise: WHITE Noise/PINK Noise

Filter Section
Type: LPF (-12 dB/-24 dB), HPF
Knobs: LPF CUTOFF, RESONANCE, HPF CUTOFF, KEY Follow
Envelope: ATTACK Time, DECAY Time, SUSTAIN Level, RELEASE Time, ENVELOPE Depth

Amplifier Section
TONE
Envelope: ATTACK Time, DECAY Time, SUSTAIN Level, RELEASE Time

LFO Section
LFO Waveform: SINE, TRIANGLE, SAW, SQUARE, Sample&Hold, Random
Knobs: FADE TIME, RATE, PITCH, FILTER, AMP
Controller: LFO KEY TRIGGER

Mixer Section
Level: OSC 1, OSC 2, SUB OSC, NOISE

Effecter Section
CRUSHER, REVERB, DELAY, DELAY TIMEStructure Elements (PLUG-OUT Mode)Depend on PLUG-OUT software



To access the MIDI control options of the SYSTEM-1m, hold down the [WRITE] button and press the [LFO KEY TRIG] button. The [LFO KEY TRIG] button will blink.
Through the Midi Learn function in your DAW it should be possible to map knobs on the hardware to different controls.
